Getting Started Manual

922136-00 Rev A

151

B

F

ILE

The File selection on the Hardcopy tab saves the screen image as a file to
storage media such as a USB drive or hard drive. Choose from either of the
following methods to save a screen image to a file:

Press the

P

RINT

front panel button. Then, touch the

Save Screen To File

button from the Print flyout menu.

PLEASE NOTE THE FOLLOWING:

The instrument's hard disk is partitioned into drive C: and drive D:.
Drive C: contains the Windows operating system and the instrument
application software. Drive D: is intended for data files.

Once you have configured your Clipboard settings from the
Hardcopy dialog (using the next procedure), you can touch the P

RINT

front panel button and touch Save Screen To File on the Print flyout
menu. The instrument automatically uses the additional file settings
to save the screen image to the file.

Touch

Utilities → Utilities Setup...

and click the

Hardcopy

tab. On the

Hardcopy dialog, touch the

File

button.

1. Touch inside the File Format data entry control and select a graphic

file format from the pop-up menu.

2. Touch the Colors control and choose Standard to print the screen as

it appears, Print to print the waveforms on a white background, or
Black & White to print the waveforms in black & white.

Note

: Choosing

Print

colors saves printer toner or ink (when you

eventually do print from the file).

3. Touch inside the File Name data entry control and provide a name

for the display image using your preferred input control method.
Additional information on using the touch screen controls can be
found in the Dialog Area

(on

page 42

)

.

4. Touch inside the Directory data entry control and provide the folder

path for the resulting printout. Or touch the Browse button and
navigate to the folder.

5. Touch the Hardcopy Area control to choose which part of the screen

you want to print. Choose Grid Area Only if you do not need to print
