WaveRunner 6 Zi and 12-Bit HRO
162
922136-00 Rev A
If you chose SMTP, touch inside the SMTP Server data entry
field and provide the name of your server. Touch inside the
Originator Address (From:) data entry field and provide the
instrument's e-mail address. Then touch inside the Default
Recipient Address (To:) data entry field and provide the
recipient's e-mail address.
3. The Overview of E-Mail modes section of the dialog provides helpful
descriptions for your Server selection (made during the first step in
this topic).
4. Use the Send Test Mail button to ensure proper E-Mail configuration
by way of sending a confirmation message.
Color
You can customize the Colors used for Channels, Math, and Memory traces
both when shown on your instrument and when used in print output.
Note
: These color settings match a waveform on the grid display (both on-screen
and printed) and show consistently on corresponding
dialogs
,
tables
, and
trace
descriptor labels
.
Numbered sections on this dialog correspond with the following
explanations.
1. Make color selections for Channels (Screen and Print) by touching
one of the color swatches. The Color pop-up control is shown and
may be used to specify your desired color.
2. Just like Channels, make color selections for Math Traces (Screen
and Print) by touching one of the color swatches. The Color pop-up
control is shown and may be used to specify your desired color.
3. Again, just like Channels, make color selections for Memory Traces
(Screen and Print) by touching one of the color swatches. The Color
pop-up control is shown and may be used to specify your desired
color.
4. You can use the Factory default colors button to instantly recall the
original color settings for your instrument.
