WaveRunner 6 Zi and 12-Bit HRO

150

922136-00 Rev A

C

LIPBOARD

The Clipboard selection on the Hardcopy tab saves the screen image on
the clipboard so you can paste a file into another application (like Microsoft
Word, for example). Choose from either of the following methods to save a
screen image to your clipboard:

Press the

P

RINT

front panel button. Then, touch the

Save Screen To

Clipboard

button from the Print flyout menu.

Note

: Once you have configured your

Clipboard

settings from the

Hardcopy

dialog (using the next procedure), you can touch the

P

RINT

front panel button and

touch

Save Screen To Clipboard

on the

Print

flyout menu. The instrument

automatically uses the additional clipboard settings to save the screen image to
the clipboard.

Touch

Utilities → Utilities Setup...

and click the

Hardcopy

tab. On the

Hardcopy dialog, touch the

Clipboard

button.

1. Touch the Colors control and choose Standard to print the

screen as it appears, Print to print the waveforms on a white
background, or Black & White to print the waveforms in black
& white.

Note

: Choosing

Print

colors saves printer toner or ink.

2. Touch the Hardcopy Area control to choose which part of the

screen you want to print. Choose Grid Area Only if you do not
need to print the dialog area and you only want to show the
waveforms and grids. Choose DSO window if you want to
print the dialogs with the waveforms and grids. Choose Full
Screen
if you want to print the entire screen.

3. Touch the Print Now button.
