IP DSLAM

523

anival

This is used to configure access node identifier. This field will be

used only when value of gsvIaAniType is config.

Type: Create -- Optional

Modify -- Optional

Default value: "\0"

aciprefixstr

This is used to configure user defined string to be concatenated as

a part of flexible syntax in Agent Circuit Id. It is a string of

characters with spaces and special characters.

Type: Create -- Optional

Modify -- Optional

Default value: "\0"

acifieldlist AniVal |

Chassis | Rack | Frame

| Slot | SubSlot |

L2Type | Port | Vpi | Vci

| VlanTag | None |

None

This field represents list of parameters which will take part in auto

generation of Agent Circuit Id.

Type: Create -- Optional

Modify -- Optional

suboption Aci | Rai |

EncapType |

AccessLoopChar |

None | None

This field represents bitmask for suboptions to be added to VSA

tag in case of PIA and Option82 tag in case of DRA. The options

which can be added include Agent Circuit Id, Agent Remote Id,

EncapType and AccessLoopCharacterstics. Agent Circuit id

identifies the circuit, Agent Remote id specifies the subscriber

information, EncapType and AccessLoopChar identify with the

encapsulation type and access loop characterstics respectively.

Type: Create -- Optional

Modify -- Optional

chassisval

Chasis number of access node

Type: Create -- Optional

Modify -- Optional

Default value: \0

rackval

Rack no of access node

Type: Create -- Optional

Modify -- Optional

Default value: \0

frameval

Frame number of access node.

Type: Create -- Optional

Modify -- Optional

Default value: \0
