Planet Technology IP DSLAM IDL-4801 User Manual
Page 41

IP DSLAM
41
a. Click on the tab of “Surveillance” that will bring the Surveillance dialogue box to
front.
b. Click on
or
to change the monitor period.
c. Select the checkbox of Save expired records to save surveillance archive,
which can be browsed by clicking on the tab of Achieved in the Event Log
window as shown in the following figure.
d. Clicking on
to choose the directory to record surveillance data and
press
or
to define expired period.
e. Click on
to submit your settings.
