IP DSLAM
329
Parameters:
Name
Description
ifname > This parameter specifies the name assigned to this interface. Type: Create - Mandatory Delete - Mandatory Get - Optional Modify - Mandatory Valid values: eoa-0,eoa-1…. lowif This parameter specifies the lower interface index. It contains ifindex of the AAL5 or VC Aggregation interface. Type: Mandatory Valid Values : aal5-0 - * pkttype {multicast |broadcast |unknownunicast}+ | all|none This parameter defines the packet type supported by the interface. ‘EoAPktTypeSupported’ shall be configured for every CPE side Ethernet interface. By default, the option taken is 'ALL' and it means that all packets will be transmitted. The value 'None' means that normal Ucast packets will be transmitted. The interface shall not transmit any other packet type than the ones configured. Type: Optional. Valid Values: {multicast |broadcast |unknown-unicast}+ | all Default Value: all. fcs false | true This specifies whether Ethernet FCS needs to be computed for the CPE side Ethernet interfaces. This can be set to true only if encaptype of the lower interface is Ethernet. Type: Optional Valid Values: false or true Default Value: false. Enable|disable Administrative status of the interface Type: Optional Valid values : enable or disable Default Values: enable inactivitytmrintrvl This field specifies the time (in seconds) after which interfaces shall be marked inactive if there is no data activity on this interface during this interval. This is used only when the bit corresponding to "ConfigEntry" is set for gsvEoaConfigStatus field. A value of zero means the timer is not running. In Aautosensing scenario, an inactive interface is a candidate to deletion in case another protocol is sensed on Atm Vc Interface on which this interface is created. Type: Optional Valid Values: 0 to 0xffffffff
