Sections/Fields Description
Extension Name This is the name of the person that the extension will be assigned to (using
this device).
Email Address This is the user’s email address (optional)
Ext. # The extension number that is assigned to this device.
Device Type This is the type of device that will be using this extension (i.e. IP550).
MAC This is the MAC ID of the device (optional).
AutoNumber/Start
At Selecting this option allows you to automatically number the extensions that
you need to add. To use this feature, simply enter the extension number you
want to start with then select (place a checkmark) the AutoNumber option.
Table 15 – Create Extension Fields and Descriptions
Add/Create Extensions
This section describes in detail how to create a new extension.
STEPS:
1 From any page of the PBX Admin system, click on the button next to the Destinations
link to expand the menu. The Destination menu opens and displays the options
available.
2 Click on the Extensions link. The Extensions page opens and displays a listing of
extensions (if ones already exists).
3 Click on the box to the left of the Extensions field. This value defaults to “10”. Enter the
number of extensions you want to add and then click the ADD button.
4 The Create Extensions page appears displaying the number of rows that was specified.
Enter information for the extension in these fields. See table above for details.
You can have the system automatically number the extensions you want to create by
clicking the AutoNumber checkbox located on the top left hand corner of the Create
Extensions page.
5 Click on the CREATE button when all the extension information you want to create is
entered. The system responds with a message indicating the results of adding the new
extension(s). You should see a “SUCCESS” message.
6 If there is an error, you will see an “ERROR” indicated under the Results field. An error is
typically due to an extension number that is being duplicated (already existing in the
system). Make the necessary adjustments to correct the error then click the CREATE
button.
7 Click on the button, to save the changes.
8 Select the Apply Changes link located on the right hand corner of the page, to commit
the changes to the database.
