The following table outlines the parameters and descriptions required for adding a new service.
Feature
Description
Service Name
This is the name of the new service and will populate the Service drop-down list in the
Add New Rule section.
Service Transport
This is the service type that will be used to transport the message. The options are
Both, TCP or UDP.
SIP and RTP traffic both occur on UDP, TFTP traffic is UDP, and Call Manager traffic is
TCP. Any other rules created would need to be configured for the protocol used by this
service.
Service Ports
This is the port information that is associated with the host. You can enter a single or
range of ports that will be used for this service. SIP uses 5060, Call Manager uses
5048, and TFTP uses 69. Other services must be configured to use the appropriate
ports.
Service Policy
This is the umbrella rule for the service, which will be further defined under Add New
Rules. The options are:
Deny List; ACCEPT ALL EXCEPT rule will apply. This will allow all traffic on the
defined port, allowing you to configure a list of Denied IP addresses.
Allow List: DROP ALL EXCEPT rule will apply. This will block all traffic on the defined
port, allowing you to configure a list of Allowed IP addresses.
Table 10 – Add New Service Settings and Descriptions
The following outlines the steps to add a new service in the PBX system.
STEPS:
1
Navigate to System
Access Control
2
Click on the Access Control List button, The Access Control List page appears.
3
From the Add New Service section, enter a Name, and select the appropriate Transport
Protocol, Ports, and Policy; then click the Create Service button.
4
The new service and its associated values will be displayed in the Service listing.
5
Click the Apply Changes link located on the right hand corner of the page, to commit the
changes to the database.
The following table outlines the parameters and descriptions required for adding a new rule.
Feature
Description
Service
This drop-down list is populated when a new services is added. This is done
in the Add New Service section.
Host(s)
This is the IP Address, Domain Name or URL of the host.
Table 11 – Add New Rule Settings and Descriptions
