186 K2 Dyno Controller User Manual 15 April 2010
Chapter 10 Settings
About pseudo post-rolls
Depending on video conditions, the controller may continue its playback to the point
where any video exists even if there is no video in the post-roll part. In this case, a still
image will be used for the subsequent video and only the timecode proceeds to the end
point of the post-roll.
(4) Angle Button Swap Turn this on to put angle buttons into Shift button operation. For
example, pressing A button triggers D button operation. When Angle
Button Swap is on, Shift button is green.
(5) Alternate T-Bar Turn this on to make T-Bar operate according to ALT setting in T-Bar
configuration. See
"Setting the T-Bar" on page 174 . Pressing Shift +
Fn + Stop switches Alternate T-Bar on/off. When Alternate T-Bar is
on, Stop button is green.
(6) PRESET SPEED
FN-PLAY This is the standard preset speed that you set manually. The playlist
plays at this speed when you press
Fn+Play .
(7) PRESET SPEED
FN-SHIFT-PLAY This is the speed at which the K2 Dyno Controller plays a playlist so
that the playlist completes at the currently configured target duration.
The K2 Dyno Controller sets this speed automatically when you cue up
a playlist. The playlist plays at this speed when you press
Fn+Shift+Play .
(8) STEP Turn this on to stop the playback every time after storing a single event
during a playlist playback.
(9) Flying M/E Turn this on to apply M/E when switching angles or changing cue up
points. During a live playback, M/E is not applied even if this setting
is turned on. For information on how to set the Flying M/E, see
"Mix
effect settings" on page 171 .
If a keyboard is connected, you can enable/disable Flying/ME by
pressing the [F1] key.
(10) OnAir Preview
Multi Channel Switches between the on-air preview and multi-channel modes.
(11) Gang Sets the option in the multi-channel mode.
If you turn the Gang mode on, operations with the T-Bar or JOG knob
are synchronized in the multiple channels selected from the channel
selection panel. For example, if you turn Gang on and select channel
C3 and C4, and press the T-Bar up to the 50% position, the video for
both the C3 and C4 channels is played at the 50% speed.
For more information about the multi-channel mode and the Gang
mode, see
"Synchronizing playback status for multi-channel (Gang)
mode channels" on page 78 .
(12) PreviewCtrl Sets the option in the on-air preview mode.
If you turn this on, the channel you set as the preview channel is set as
the operation target. The preview channel is set using
"RECORDTRAIN" on the CONFIG screen. For more information
about the playback operation in the on-air preview mode, see
"Playback operations in the on-air preview mode" on page 73 .
(13) Channel selection If PreviewCtrl is turned on, the channel of the preview channel is
selected.
If
Gang is turned on, select multiple channels of which operations are
to be synchronized.
No. Name Function
