15 April 2010 K2 Dyno Controller User Manual 165
Record train length allocation settings
2. Set items.
• For information about the indication meanings and individual panel functions,
see the following table.
3. Touch APPLY .
• When you touch APPLY , the settings are reflected.
• When you touch CANCEL, the settings are restored to the settings before
changes were made.
No. Name Function
(1) Recorder Touch a camera name panel to change its camera name.
If
LOOP REC is turned on, you can set the maximum recording time
for each train by touching a train length panel and entering the timecode.
The train length must be set as values of 00:06:00,00 or longer.
(2) Player Assign players to the P1 or P2 button on the controller. Turn on P1 /
PGM to assign a player to the P1 button, which becomes the program
channel (the channel for an on-air broadcast). Turn on P2/PVW to
assign a player to the P2 button, which becomes the preview channel.
You can assign either one of the P1 or P2 button to the Player. In
addition, you cannot assign the same button to multiple channels.
(3) LOOP REC Indicates whether the LoopRec setting is turned on in the current session.
(1)
(2)
(3)
