Hardware Preparation and Installation
ATCA-7470 Installation and Use (6806800P15K) 60
2.5.3 Accelerator Module
The ATCA-7470 provides the possibility to assemble the ATCA-7470-Accelerator module. The
ATCA-7470-Accelerator module is equipped with two additional Intel DH8920CC SKU4 PCH
devices.
Installation Procedure
To install the accelerator module:
1. Remove the blade from the system.
2. Insert the Accelerator module in the socket so that the module's standoffs fit in the blade's
mounting holes.
3. Fasten the Accelerator module to the blade using the three M2.5x 8mm screws.
4. Reinstall the blade into the system.
Removal Procedure
Damage of Circuits
Electrostatic discharge and incorrect module installation and removal can damage circuits
or shorten their life.
Before touching the module or electronic components, make sure that you are working in
an ESD-safe environment.
Damage of Circuits
Electrostatic discharge and incorrect module installation and removal can damage circuits
or shorten their life.
Before touching the module or electronic components, make sure that you are working in
an ESD-safe environment.
