Hardware Preparation and Installation
ATCA-7470 Installation and Use (6806800P15K) 58
Removal Procedure
To remove a DIMM module, proceed as follows:
1. Remove blade from system as described in Installing and Removing the Blade on
page 61 .
2. Open locks of socket at both sides.
The memory module is automatically lifted up.
3. Remove module from socket.
4. Repeat steps 2 to 3 in order to remove further memory modules.
2.5.2 MO297 SSD Module
The SATA module consists of a Solid State Disc of up to 256 GB and a SATA controller and
connects physically to PCH Sata Port #4.
The MO297 SSD module is an accessory kit and is not part of the default ATCA-7470. The
following procedure describes the steps to install/remove the MO297 SSD module.
Installation Procedure
To install an MO297 SSD module, proceed as follows:
Damage of Circuits
Electrostatic discharge and incorrect module installation and removal can damage circuits
or shorten their life.
Before touching the module or electronic components, make sure that you are working in
an ESD-safe environment.
