Quartus II IP
files
bitec_reconfig_alt_
.qip
bitec_clkrec_dist.qip
bitec_clkrec.qip
Quartus II IP files that list the required
submodule files.
Scripts
runall.tcl
Script to set up the project, generate the IP and
Qsys system, and compile.
assignments.tcl
Top-level TCL file to create the project
assignments.
build_ip.tcl
TCL file to build the DisplayPort example
design IP blocks.
build_sw.sh
Script to compile the software.
Miscellaneous
example.sdc
Top-level SDC file.
bitec_clkrec.sdc
Clock recovery core SDC file.
Software files
(in the
software
directory)
dp_demo_src\
Directory containing the example application
source code.
btc_dprx_syslib\
System library for the RX API.
btc_dptx_syslib\
System library for the TX API.
Build the FPGA Design
In this step, you use a script to build and compile the FPGA design. Type the command:
./runall.tcl
This script basically builds the IPs and software, as well as performs Quartus full compilation.
Load, and Run the Software
In this step you load the software into the device, and run the software.
1. In a Windows Command Prompt, navigate to the hardware demonstration software directory.
2. Launch a Nios II command shell. You can launch it using several methods, for example, from the
Windows task bar or within the Qsys system.
3. From within the Nios II command shell execute the following command to program the device,
download the Nios II program, and launch a debug terminal:
nios2-configure-sof
<USB cable
number>
