Page 42
Parameter
Description
16-bpc RGB or YCbCr 4:4:4 (48 bpp)
Turn on to support 48 bpp decoding.
8-bpc YCbCr 4:2:2 (16 bpp)
Turn on to support 16 bpp decoding. Reserved for
future use.
10-bpc YCbCr 4:2:2 (20 bpp)
Turn on to support 20 bpp decoding. Reserved for
future use.
12-bpc YCbCr 4:2:2 (24 bpp)
Turn on to support 24 bpp decoding. Reserved for
future use.
16-bpc YCbCr 4:2:2 (32 bpp)
Turn on to support 32 bpp decoding. Reserved for
future use.
Support MST
Turn on to enable multi-stream support.
You have to turn on Enable GPU control to support
MST.
Max stream count
Select the maximum amount of streams supported
(1-4).
Sink Interfaces
The following tables summarize the sink’s interfaces. Your instantiation contains only the interfaces that
you have enabled.
Table 5-2: Controller Interface
Interface
Port Type
Clock Domain
Port
Direction
Description
clk
Clock
N/A
clk
Input
Clock for embedded
controller
reset
Reset
clk
reset
Input
Reset for embedded
controller
5-6
Sink Interfaces
UG-01131
2015.05.04
Altera Corporation
DisplayPort Sink
