June 2014
2014.06.30
• Native PHY is removed from the IP core; included information
about how to instantiate the PHY outside the DisplayPort IP core.
• Updated the source and sink block diagrams.
• Updated the source and sink register map information.
• Added new sink register bits:
•
LQA ACTIVE
•
PHY_SINK_TEST_LANE_SEL
•
PHY_SINK_TEST_LANE_EN
•
AUX_IRQ_EN
•
TX_STROBE
•
DPRX_AUX_STATUS
bits
•
DPRX_AUX_I2C0
bits
•
DPRX_AUX_I2C0
bits
•
DPRX_AUX_HPD
bits
• Removed these sink register bits:
•
HPD_IRQ
•
HPD_EN
•
DPRX_AUX_IRQ_EN
bits
• Added a new source register bit:
•
VTOTAL
• Added source TX transceiver interface signals
• Removed these source signals:
•
xcvr_refclk
•
tx_serial_data
•
xcvr_reconfig
• Added sink audio and RX transceiver interface signals.
• Removed these sink signals:
•
xcvr_refclk
•
rx_serial_data
•
xcvr_reconfig
• Added information about Transceiver Reconfiguration Interface for
source and sink.
• Added information about single clock reference (135MHz) for
source and sink.
• Added information about Bitec HSMC DisplayPort daughter card
in the Hardware Demonstration chapter.
• Updated the API reference.
