Bit Bit Name Function
7:0 BYTE Transaction data(11) received in the last request, or data(14)
for the next reply
DPRX_AUX_BYTE15
AUX Transaction Byte 15 Register.
Address: 0×0112
Direction: RW
Reset: 0×00000000
Table 10-60: DPRX_AUX_BYTE15 Bits
Bit Bit Name Function
31:8 Unused
7:0 BYTE Transaction data(12) received in the last request, or
data(15) for the next reply
DPRX_AUX_BYTE16
AUX Transaction Byte 16 Register.
Address: 0×0113
Direction: RW
Reset: 0×00000000
Table 10-61: DPRX_AUX_BYTE16 Bits
Bit Bit Name Function
31:8 Unused
7:0 BYTE Transaction data(13) received in the last request
DPRX_AUX_BYTE17
AUX Transaction Byte 17 Register.
Address: 0×0114
Direction: RW
Reset: 0×00000000
10-30 DPRX_AUX_BYTE15
UG-01131
2015.05.04
Altera Corporation DisplayPort Sink Register Map and DPCD Locations
