Btc_dptx_baseaddr, Btc_dptx_edid_block_read, Btc_dptx_baseaddr -15 – Altera DisplayPort MegaCore Function User Manual
Page 116: Btc_dptx_edid_block_read -15
Related Information
btc_dptx_baseaddr
Prototype:
unsigned int btc_dptx_baseaddr(void)
Thread-safe:
Yes
Available from ISR:
Yes
Include:
<
btc_dptx_syslib.h
>
Return:
0 = success, 1 = fail
Parameters:
No
Description:
This function returns the base address of the TX instance connected to the
given port number.
Example:
addr = btc_dptx_baseaddr();
btc_dptx_edid_block_read
Prototype:
int btc_dptx_edid_block_read(
BYTE block,
BYTE *data)
Thread-safe:
No
Available from ISR:
Yes
Include:
<
btc_dptx_syslib.h
>
Return:
0 = success, 1 = fail
Parameters:
•
block
—Block number (0 - 3)
•
data—
Pointer for data to be read
Description:
Reads one block (128 bytes) from the EDID of the connected DisplayPort sink.
Example:
btc_dptx_edid_block_read(2, pdata);
UG-01131
2015.05.04
btc_dptx_baseaddr
8-15
DisplayPort API Reference
Altera Corporation
