DP RX Connector J1
PWR_OUT
Output
DP_PWR
3.3V @ 500mA for sink-side cable adapter.
A standard DisplayPort cable must have no wire for
this pin.
DP RX Connector J2
CONFIG1
Input
Cable Adapter Detect for dual mode support.
CONFIG2
Not used
—
RTN_PWR
Input
Return signal for
DP_PWR
.
PWR_OUT
Output
DP_PWR
3.3V @ 500mA for source-side cable
adapter.
A standard DP cable must have no wire for this pin.
Example 6-1: Main Link Re-driver Programming Example
Bitec DP daughter card has Main Link redriver (SN75DP130) that boosts link performance. In
typical applications, the redriver EQ, VOD/pre-emphasis levels can be set automatically based on
link training. In some cases, you may want to manually configure the settings. The following is an
example code that manually configures the redriver EQ, VOD/Pre-emphasis settings.
Note: The bitec_i2c_write() function is called inside
main.c
in the demonstration
software. I
2
C address 0×58 is the write address for the RX redriver.
//*********************************************************
// Disable link training (DP130 reg=0×04, data=0×00)
//*********************************************************
// Disable DP130 link training to enable I2C programming
bitec_i2c_write(0×58, 0×04, 0×00);
//*********************************************************
// Program link bandwidth settings to HBR2 (DPCD addr=0×00100, data=0×14)
//*********************************************************
bitec_i2c_write(0×58, 0×1c, 0×00); // DPCD addr[19:16]=0×0
bitec_i2c_write(0×58, 0×1d, 0×01); // DPCD addr[15:8]=0×01
bitec_i2c_write(0×58, 0×1e, 0×00); // DPCD add[7:0]=0×00
bitec_i2c_write(0×58, 0×1f, 0×14); // DPCD data=0×14
//*********************************************************
// Program lane count to 4 (DPCD addr=0x00101, data=0x4)
//*********************************************************
bitec_i2c_write(0×58, 0×1c, 0×00); // DPCD addr[19:16]=0×0
bitec_i2c_write(0×58, 0×1d, 0×01); // DPCD addr[15:8]=0×01
bitec_i2c_write(0×58, 0×1e, 0×01); // DPCD addr[7:0]=0×01
bitec_i2c_write(0×58, 0×1f, 0×04); // DPCD data=0×4
//*********************************************************
// Program VOD Level 1 and Pre-emphasis Level 0 for lane 0
// (DPCD addr=0×00103, data=0×01)
//*********************************************************
bitec_i2c_write(0×58, 0×1c, 0×00); // DPCD addr[19:16]=0×0
bitec_i2c_write(0×58, 0×1d, 0×01); // DPCD addr[15:8]=0×01
bitec_i2c_write(0×58, 0×1e, 0×03); // DPCD addr[7:0]=0×03
bitec_i2c_write(0×58, 0×1f, 0×01); // DPCD data=0×01
