For transaction replies:
1. Issue a transaction request.
2. Wait for
MSG_READY
to be 1. Implement a timeout.
3. Read the transaction reply’s total length from
LENGTH
.
4. Read the transaction reply's command from the
DPTX_AUX_COMMAND
register. This transaction clears
MSG_READY
and
LENGTH
.
5. Read the transaction reply's data payload from registers
DPTX_AUX_BYTE0
to
DPTX_AUX_BYTE15
(read
LENGTH
- 1 bytes).
Address: 0×0100
Direction: RW
Reset: 0×00000000
Table 9-39: DPTX_AUX_CONTROL Bits
Bit
Bit Name
Function
31
MSG_READY
0 = Waiting for a reply
1 = A reply has been completely received
30
READY_TO_TX
0 = Busy sending a request or waiting for a reply
1 = Ready to send a request
29:5
Unused
4:0
LENGTH
For the next transaction request, total length of message to
be transmitted (3 – 20), for the last received transaction
reply, total length of message received (1 – 17).
DPTX_AUX_CMD
Address: 0×0101
Direction: RW
Reset: 0×00000000
Table 9-40: DPTX_AUX_CMD Bits
Bit
Bit Name
Function
31:8
Unused
7:0
COMMAND
AUX transaction command for the next request or
received in the most recent reply (refer to the Display‐
Port specification for details). Reading of this register
clears
MSG_READY
and
LENGTH
in
DPTX_AUX_CONTROL
register.
