Altera DisplayPort MegaCore Function User Manual
Page 151
Location Name
Address
PAYLOAD_ALLOCATE_START_TIME_SLOT
0×01C1
PAYLOAD_ALLOCATE_TIME_SLOT_COUNT
0×01C2
SINK_COUNT
0×0200
DEVICE_SERVICE_IRQ_VECTOR
0×0201
LANE0_1_STATUS
0×0202
LANE2_3_STATUS
0×0203
LANE_ALIGN_STATUS_UPDATED
0×0204
SINK_STATUS
0×0205
ADJUST_REQUEST_LANE0_1
0×0206
ADJUST_REQUEST_LANE2_3
0×0207
SYMBOL_ERROR_COUNT_LANE0
0×0210
SYMBOL_ERROR_COUNT_LANE1
0×0212
SYMBOL_ERROR_COUNT_LANE2
0×0214
SYMBOL_ERROR_COUNT_LANE3
0×0216
TEST_REQUEST
0×0218
TEST_LINK_RATE
0×0219
TEST_LANE_COUNT
0×0220
PHY_TEST_PATTERN
0×0248
TEST_80BIT_CUSTOM_PATTERN (0×0250 to 0×0259)
0×0250
TEST_RESPONSE
0×0260
TEST_EDID_CHECKSUM
0×0261
PAYLOAD_TABLE_UPDATE_STATUS
0×02C0
VC_PAYLOAD_ID_SLOT_1 (0×02C1 to 0×02FF)
0×02C1
SET_POWER_STATE
0×0600
DOWN_REQ (0×1000 to 0×102F)
0×1000
UP_REP (0×1200 to 0×122F)
0×1200
DOWN_REP (0×1400 to 0×142F)
0×1400
UP_REQ (0×1600 to 0×162F)
0×1600
9-30
Source-Supported DPCD Locations
UG-01131
2015.05.04
Altera Corporation
DisplayPort Source Register Map and DPCD Locations
