Page 184
Bit
Bit Name
Function
12
HPD_IRQ
Writing this bit at 1 generates a 0.75-ms long HPD IRQ (low pulse).
This bit is WO.
To use this bit,
HPD_EN
must be 1.
11
HPD_EN
HPD logic level
0 = Deasserted (low)
1 = Asserted (high)
10:0
Unused
Sink-Supported DPCD Locations
The following table describes the DPCD locations (or location groups) that are supported in DisplayPort
sink instantiations.
Table 10-68: DPCD Locations
Location Name
Address
Without
Controller
With Controller
DPCD_REV
0×0000
Yes
Yes
MAX_LINK_RATE
0×0001
Yes
Yes
MAX_LANE_COUNT
0×0002
Yes
Yes
MAX_DOWNSPREAD
0×0003
Yes
Yes
NORP
0×0004
Yes
Yes
DOWNSTREAMPORT_PRESENT
0×0005
Yes
Yes
MAIN_LINK_CHANNEL_CODING
0×0006
Yes
Yes
DOWN_STREAM_PORT_COUNT
0×0007
Yes
Yes
RECEIVE_PORT0_CAP_0
0×0008
Yes
Yes
RECEIVE_PORT0_CAP_1
0×0009
Yes
Yes
RECEIVE_PORT1_CAP_0
0×000A
Yes
Yes
RECEIVE_PORT1_CAP_1
0×000B
Yes
Yes
I2C_SPEED_CONTROL
0×000C
—
Yes
UG-01131
2015.05.04
Sink-Supported DPCD Locations
10-33
DisplayPort Sink Register Map and DPCD Locations
Altera Corporation
