Altera DisplayPort MegaCore Function User Manual
Page 123
Reset: 0×00000000
Table 9-2: DPTX_TX_CONTROL Bits
Bit
Bit Name
Function
31
HPD_IRQ_EN
Enables an IRQ issued to the Nios II processor on an HPD event:
• 0 = disable
• 1 = enable
30
AUX_IRQ_EN
Enables an IRQ issued to the Nios II processor when an AUX
channel transaction reply is received from the sink:
• 0 = disable
• 1 = enable
29
Unused
28:21
TX_LINK_RATE
Main link rate expressed as multiples of 270 Mbps:
• 0×06 = 1.62 Gbps
• 0×0a = 2.7 Gbps
• 0×14 = 5.4 Gbps
20
Reserved
Reserved
19
ENHANCED_FRAME
0 = Standard framing
1 = Enhanced framing
18:15
Unused
14
ASYNC_CLOCK
0 = Synchronous (reserved for future use)
1 = Asynchronous
Note: The core only supports asynchronous clock mode for
14.1 release. The register bit is always set to 1.
13:10
Unused
9:5
LANE_COUNT
Lane count:
• 00000 = Reserved
• 00001 = 1
• 00010 = 2
• 00100 = 4
4
Unused
9-2
DPTX_TX_CONTROL
UG-01131
2015.05.04
Altera Corporation
DisplayPort Source Register Map and DPCD Locations
