Table 10-62: DPRX_AUX_BYTE17 Bits
Bit Bit Name Function
31:8 Unused
7:0 BYTE Transaction data(14) received in the last request
DPRX_AUX_BYTE18
AUX Transaction Byte 18 Register.
Address: 0×0115
Direction: RW
Reset: 0×00000000
Table 10-63: DPRX_AUX_BYTE18 Bits
Bit Bit Name Function
31:8 Unused
7:0 BYTE Transaction data(15) received in the last request
DPRX_AUX_I2C0
AUX to I2C0 management. The sink routes all AUX channel accesses to I 2 C slave addresses of values
between
START_ADDR
and
END_ADDR
to I2C0.
Address: 0×0116
WO
0×00000000
Table 10-64: DPRX_AUX_I2C0 Bits
Bit Bit Name Function
31:15 Unused
14:8 END_ADDR I 2 C slave end address
7 Unused
6:0 START_ADDR I 2 C slave start address
DPRX_AUX_I2C1
AUX to I2C1 management. The sink routes all AUX channel accesses to I 2 C slave addresses of values
between
START_ADDR
and
END_ADDR
to I2C1.
