Dptx_aux_byte12, Dptx_aux_byte13, Dptx_aux_byte12 -26 – Altera DisplayPort MegaCore Function User Manual
Page 147: Dptx_aux_byte13 -26
Direction: RW
Reset: 0×00000000
Table 9-52: DPTX_AUX_BYTE11 Bits
Bit
Bit Name
Function
31:8
Unused
7:0
BYTE
Transaction data(8) for the next request, or data(11)
received in the last reply
DPTX_AUX_BYTE12
AUX Transaction Byte 12 Register.
Address: 0×010e
Direction: RW
Reset: 0×00000000
Table 9-53: DPTX_AUX_BYTE12 Bits
Bit
Bit Name
Function
31:8
Unused
7:0
BYTE
Transaction data(9) for the next request, or data(12)
received in the last reply
DPTX_AUX_BYTE13
AUX Transaction Byte 13 Register.
Address: 0×010f
Direction: RW
Reset: 0×00000000
Table 9-54: DPTX_AUX_BYTE13 Bits
Bit
Bit Name
Function
31:8
Unused
7:0
BYTE
Transaction data(10) for the next request, or data(13)
received in the last reply
9-26
DPTX_AUX_BYTE12
UG-01131
2015.05.04
Altera Corporation
DisplayPort Source Register Map and DPCD Locations
