Dptx_mst_vcptab2, Dptx_mst_vcptab2 -16 – Altera DisplayPort MegaCore Function User Manual
Page 137
Table 9-31: DPTX_MST_VCPTAB1 Bits
Bit
Bit Name
Function
31:28
VCPSLOT15
VC payload ID or slot 15
27:24
VCPSLOT14
VC payload ID or slot 14
23:20
VCPSLOT13
VC payload ID or slot 13
19:16
VCPSLOT12
VC payload ID or slot 12
15:12
VCPSLOT11
VC payload ID or slot 11
11:8
VCPSLOT10
VC payload ID or slot 10
7:4
VCPSLOT9
VC payload ID or slot 9
3:0
VCPSLOT8
VC payload ID or slot 8
DPTX_MST_VCPTAB2
VC Payload ID Table
Address: 0×00a4
Direction: RW
Reset: 0×00000000
Table 9-32: DPTX_MST_VCPTAB2 Bits
Bit
Bit Name
Function
31:28
VCPSLOT23
VC payload ID or slot 23
27:24
VCPSLOT22
VC payload ID or slot 22
23:20
VCPSLOT21
VC payload ID or slot 21
19:16
VCPSLOT20
VC payload ID or slot 20
15:12
VCPSLOT19
VC payload ID or slot 19
11:8
VCPSLOT18
VC payload ID or slot 18
7:4
VCPSLOT17
VC payload ID or slot 17
3:0
VCPSLOT16
VC payload ID or slot 16
9-16
DPTX_MST_VCPTAB2
UG-01131
2015.05.04
Altera Corporation
DisplayPort Source Register Map and DPCD Locations
