Dptx_mst_vcptab7, Dptx_mst_vcptab7 -19 – Altera DisplayPort MegaCore Function User Manual
Page 140
Table 9-36: DPTX_MST_VCPTAB6 Bits
Bit
Bit Name
Function
31:28
VCPSLOT55
VC payload ID or slot 55
27:24
VCPSLOT54
VC payload ID or slot 54
23:20
VCPSLOT53
VC payload ID or slot 53
19:16
VCPSLOT52
VC payload ID or slot 52
15:12
VCPSLOT51
VC payload ID or slot 51
11:8
VCPSLOT50
VC payload ID or slot 50
7:4
VCPSLOT49
VC payload ID or slot 49
3:0
VCPSLOT48
VC payload ID or slot 48
DPTX_MST_VCPTAB7
VC Payload ID Table
Address: 0×00a9
Direction: RW
Reset: 0×00000000
Table 9-37: DPTX_MST_VCPTAB7 Bits
Bit
Bit Name
Function
31:28
VCPSLOT63
VC payload ID or slot 63
27:24
VCPSLOT62
VC payload ID or slot 62
23:20
VCPSLOT61
VC payload ID or slot 61
19:16
VCPSLOT60
VC payload ID or slot 60
15:12
VCPSLOT59
VC payload ID or slot 59
11:8
VCPSLOT58
VC payload ID or slot 58
7:4
VCPSLOT57
VC payload ID or slot 57
3:0
VCPSLOT56
VC payload ID or slot 56
UG-01131
2015.05.04
DPTX_MST_VCPTAB7
9-19
DisplayPort Source Register Map and DPCD Locations
Altera Corporation
