Altera DisplayPort MegaCore Function User Manual
Page 70
Interface
Port Type
Clock Domain
Port
Direction
Description
Video Input
Conduit
vidin_clk
vidin_clk
Input
Pixel clock.
vidin_data
(BPP*PIXEL
S_PER_
CLOCK–1:0)
Input
Pixel data.
vidin_valid
Input
You must assert this
signal when all signals on
this port are valid.
vidin_sol
Input
Start of video line.
vidin_eol
Input
End of video line.
vidin_sof
Input
Start of video frame.
vidin_eof
Input
End of video frame.
vidin_
locked
Input
You must assert this
signal when the Display‐
Port RX is locked to a
valid received video
stream.
• 1 = Video locked
• 0 = Video unlocked
UG-01131
2015.05.04
Clock Recovery Interface
6-9
DisplayPort IP Core Hardware Demonstration
Altera Corporation
