Dptx0_msa_misc0, Dptx0_msa_misc1, Dptx0_msa_colour – Altera DisplayPort MegaCore Function User Manual
Page 129: Dptx0_msa_misc0 -8, Dptx0_msa_misc1 -8, Dptx0_msa_colour -8
Table 9-15: DPTX0_MSA_VHEIGHT Bits
Bit
Bit Name
Function
31:16
Unused
15:0
VHEIGHT
Main stream attribute
VHEIGHT
DPTX0_MSA_MISC0
Address: 0×002c
Direction: RO
Reset: 0×00000000
Table 9-16: DPTX0_MSA_MISC0 Bits
Bit
Bit Name
Function
31:8
Unused
7:0
MISC0
Main stream attribute MISC0
DPTX0_MSA_MISC1
Address: 0×002d
Direction: RO
Reset: 0×00000000
Table 9-17: DPTX0_MSA_MISC1 Bits
Bit
Bit Name
Function
31:8
Unused
7:0
MISC1
Main stream attribute MISC1
DPTX0_MSA_COLOUR
Address: 0×002e
Direction: RW
Reset: 0×00000001
9-8
DPTX0_MSA_MISC0
UG-01131
2015.05.04
Altera Corporation
DisplayPort Source Register Map and DPCD Locations
