Dprx0_msa_hwidth, Dprx0_msa_vheight, Dprx0_msa_misc0 – Altera DisplayPort MegaCore Function User Manual
Page 163: Dprx0_msa_hwidth -12, Dprx0_msa_vheight -12, Dprx0_msa_misc0 -12
Direction: RO
Reset: 0×00000000
Table 10-19: DPRX0_MSA_VSW Bits
Bit
Bit Name
Function
31:15
Unused
14:0
VSW
Main stream attribute vertical synchronization width
DPRX0_MSA_HWIDTH
TX control register,
DPRX0_MSA_HWIDTH
.
Address: 0×002a
Direction: RO
Reset: 0×00000000
Table 10-20: DPRX0_MSA_HWIDTH Bits
Bit
Bit Name
Function
31:16
Unused
15:0
HWIDTH
Main stream attribute HWIDTH
DPRX0_MSA_VHEIGHT
Address: 0×002b
Direction: RO
Reset: 0×00000000
Table 10-21: DPRX0_MSA_WHEIGHT Bits
Bit
Bit Name
Function
31:16
Unused
15:0
VHEIGHT
Main stream attribute
VHEIGHT
DPRX0_MSA_MISC0
Address: 0×002c
Direction: RO
Reset: 0×00000000
10-12
DPRX0_MSA_HWIDTH
UG-01131
2015.05.04
Altera Corporation
DisplayPort Sink Register Map and DPCD Locations
