Dptx_aux_byte14, Dptx_aux_byte15, Dptx_aux_byte16 – Altera DisplayPort MegaCore Function User Manual
Page 148: Dptx_aux_byte14 -27, Dptx_aux_byte15 -27, Dptx_aux_byte16 -27
DPTX_AUX_BYTE14
AUX Transaction Byte 14 Register.
Address: 0×0110
Direction: RW
Reset: 0×00000000
Table 9-55: DPTX_AUX_BYTE14 Bits
Bit
Bit Name
Function
31:8
Unused
7:0
BYTE
Transaction data(11) for the next request, or data(14)
received in the last reply
DPTX_AUX_BYTE15
AUX Transaction Byte 15 Register.
Address: 0×0111
Direction: RW
Reset: 0×00000000
Table 9-56: DPTX_AUX_BYTE15 Bits
Bit
Bit Name
Function
31:8
Unused
7:0
BYTE
Transaction data(12) for the next request, or data(15)
received in the last reply
DPTX_AUX_BYTE16
AUX Transaction Byte 16 Register.
Address: 0×0112
Direction: RW
Reset: 0×00000000
Table 9-57: DPTX_AUX_BYTE16 Bits
Bit
Bit Name
Function
31:8
Unused
7:0
BYTE
Transaction data(13) for the next request
UG-01131
2015.05.04
DPTX_AUX_BYTE14
9-27
DisplayPort Source Register Map and DPCD Locations
Altera Corporation
