Publication 1398-5.0 – October 1998
Installation 5-7
Allen-Bradley AC Line Filters
An AC line filter is not required on the auxiliary line input, when it is
used. Refer to “Options and Accessories” on page A-2 for part
numbers.
Mounting dimensions for single and three phase AC line filters
available from Allen-Bradley are illustrated in Figure 5.2 and
Figure 5.3, with corresponding numbers in Table 5.2 and Table 5.3.
Wiring diagrams for Allen-Bradley AC line filters follow in
Figure 5.4.
Table 5.1: Qualified AC Line Filters
Drive Manufacturer and Part Number
Schaffner
(1-800-367-5566)
Roxburgh
(01724-281770)
(011 44 1724 281770 from the USA)
1398-DDM-010 and
1398-DDM-010X FN 350-12 MIF 10 or MDF 16
1398-DDM-020 and
1398-DDM-020X FN 350-20 MIF 23 or MDF 18
1398-DDM-030 and
1398-DDM-030X FN 350-30 MIF 32 or MDF 36
1398-DDM-075 and
1398-DDM-075X FN 351-36 MIF 330 or MDF 336
1398-DDM-150 and
1398-DDM-150X MDF 350
Note: The ordering of an Allen-Bradley part number will result in a
Roxburgh line filter being received.
!
Intro
ATTENTION: Large leakage currents exist in AC line
filters. They must be grounded properly before applying
power. Filter capacitors retain high voltages after power
removal. Before handling the equipment, voltages should
be measured to determine safe levels prior to handling the
equipment. Failure to observe this precaution could result
in severe bodily injury.
