Publication 1398-5.0 – October 1998
A-6 Options and Accessories
Connector Kits
Connector kits provide the ability to construct custom length cables.
Kits are available for all ULTRA 200 Series connectors. Each kits
consists of the appropriate 3M connector with the corresponding
plastic backshell, and instructions.
Mating Connectors
The following connectors are listed solely to provide a cross-reference
of mating connectors for the J1, J2 or J3 connectors on the
ULTRA 200 Series drives. The connectors are not available from
Allen-Bradley. Please contact the manufacturer or a distributor for
additional information. Manufacturer phone numbers are:
3M: 1-800-225-5373,
AMP: 1-800-522-6752
ULTRA 200 Series drive conformance to the European EMC
Directive is contingent on the use of Allen-Bradley cables.
Connector Type Part Number
J1 50 pin mini D-shell, 24-30 AWG ribbon cable solder
cup, squeeze latch 9101-1476
J2 20 pin mini D-shell, 24-30 AWG ribbon cable solder
cup, squeeze latch 9101-1477
J3 26 pin mini D-shell, 24-30 AWG ribbon cable solder
cup, squeeze latch 9101-1478
J4 or J5 50 pin D-shell solder cup for RS-232 or RS-485 9101-1479
DDM Mating Connector Mating Backshell Description
J1 AMP 2-175677-7 AMP 176793-7 50-pin Mini D Ribbon, 28-30 AWG, Insulation
Displacement, Plastic Backshell, Squeeze
Latch
3M 10150-6000EC
1
3M 10350-A200-00 50-pin Mini D Ribbon, 28-30 AWG, Insulation
Displacement, Metal Backshell, Squeeze
Latch
3M 10150-3000VE 3M 10350-52F0-008 50-pin Mini D Ribbon, 24-30 AWG, Solder Cup,
Plastic Backshell, Squeeze Latch
J2 AMP 2-175677-2 AMP 176793-2 20-pin Mini D Ribbon, 28-30 AWG, Insulation
Displacement, Plastic Backshell, Squeeze
Latch
3M 10120-6000EC 1 3M 10320-A200-00 20-pin Mini D Ribbon, 28-30 AWG, Insulation
Displacement, Metal Backshell, Squeeze
Latch
3M 10120-3000VE 3M 10320-52F0-008 20-pin Mini D Ribbon, 24-30 AWG, Solder Cup,
Plastic Backshell, Squeeze Latch
J3 AMP 2-175677-4 AMP 176793-4 26-pin Mini D Ribbon, 28-30 AWG, Insulation
Displacement, Plastic Backshell, Squeeze
Latch
3M 10126-6000EC
1
3M 10326-A200-00 26-pin Mini D Ribbon, 28-30 AWG, Insulation
Displacement, Metal Backshell, Squeeze
Latch
3M 10126-3000VE 3M 10326-52F0-008 26-pin Mini D Ribbon, 24-30 AWG, Solder Cup,
Plastic Backshell, Squeeze Latch
1. For use with MDR Hand Press Tool Kit, 3M part number 3829
