C-6 TouchPad Instructions
Supplemental Instructions Motor Selection
Enter a Motor Identification number to load the correct motor
parameters into the drive. Table C.2 and Table C.3 list the motors
available in the motor table directory.
Displays
Selection of a motor defines default operating parameters for the drive
and motor combination.
Text
A drive name longer than eight characters may require scrolling with
the Left,
, and Right, , arrow keys. Drive names may be up to 32
characters in length.
Flashing characters in the Modify mode display are the characters that
are active.
●
Change the cursor position and resolution using the and
keys.
For example: If the Drv Name in the Modify mode displays
InFeed with the F flashing, pressing the key causes the first e
to flash.
●
Press the or keys to increment or decrement a character by
scrolling through the list of valid ASCII characters.
For example, If the Drv Name in the Modify mode displays
InFfed with the lowercase f is flashing, pressing the key causes
the flashing character to decrement to e .
Numeric
Flashing characters in the Modify mode display are the numbers that
are active.
●
Change the cursor position and resolution using the or key.
For example: If the Over Spd in the Modify mode displays 5200
and 52 is flashing, pressing the key causes 520 to flash.
●
Press the or key to increment or decrement these numbers.
For example: If the Over Spd value is 5200 and 52 is flashing,
pressing the key causes the setting to increment by 100 rpm
each time the key is pressed.
●
Parameter values may not exceed the maximum or minimum
limits, regardless of the cursor position.
