Cable Diagrams, Schematics and Examples
B-19
Figure B.17
J2 to N-Series Encoder Cable (P/N 9101-1468)
Intro
F
G
P
R
V
S
L
U
K
H
J
T
N
C
D
E
B
A
M
KPSE05E14-19S-A71 CONNECTOR
(FACE VIEW)
WIRING DIAGRAM
N/C
N
N/C
P
N/C
CONNECTOR BACKSHELL SHIELDED 360° (BOTH ENDS)
ORANGE 28 AWG
VIOLET 28 AWG
WHITE/VIOLET 28 AWG
WHITE/RED 28 AWG
GREEN 28 AWG
WHITE/GREEN 28 AWG
WHITE/ORANGE 28 AWG
BROWN 28 AWG
WHITE/BROWN 28 AWG
N/C
N/C
A
B
C
D
E
F
H
R
S
G
U
V
T
K
J
L
M
20 AWG
20 AWG
20 AWG
20 AWG
DENOTES TWISTED PAIR
DRAIN
20
19
18
17
16
13
15
14
12
11
8
10
9
7
GRAY 16 AWG
WHITE/GRAY 16 AWG
BLUE 28 AWG
WHITE/BLUE 28 AWG
BLACK 28 AWG
WHITE/BLACK 28 AWG
RED 28 AWG
28 AWG
28 AWG
28 AWG
28 AWG
6
5
4
2
3
1
PIN 1 THIS END
PIN 11 THIS END
20 POSITION
PLUG CABLE CONNECTOR
(FACE VIEW)
ш0.38
12±0.5
60°
1.62
0.55
0.63
2.24
1.42
ш 1.16
1.33
0.94
3.28
"E" ft.
CABLE, SINE #KA-50203,
ULTIMAX 80°C 30 VOLT,
ONE 16 AWG TWISTED PAIR,
EIGHT 28 AWG TWISTED PAIRS,
FOIL SHIELD WITH 100% COVERAGE,
BRAIDED SHIELD WITH 85% MINIMUM
COVERAGE AND 28 AWG DRAIN WIRE.
MOLDING ADAPTER, ALUMINUM,
BLACK COBALT PLATED
P
R
V
F
G
S
L
U
K
H
J
T
N
C
D
E
B
A
M
PIN 1 THIS END
PIN 11 THIS END
20 POSITION
PLUG CABLE CONNECTOR
M2.6 x 0.45 RETRACTABLE
MACHINED THUMBSCREW
(FASTENS DIRECTLY TO
BOARD CONNECTOR)
CONNECTOR, ITT CANNON
#KPSE05E14-19S-A71
MARK WITH ASSY P/N & REV.,
MFG P/N, REV., & DATE CODE.
OVERMOLDING,
PVC, BLACK
