Publication 1398-5.0 – October 1998
11-2 Maintenance and Troubleshooting
EEPROM Personality Module
The serial EEPROM, or personality module, stores all the drive setup
parameters. The setup parameters configure the drive to match a
particular motor and operate in a particular mode of operation.
The personality module may be removed from a ULTRA 200 Series
drive and installed in another drive. By transferring the personality
module from a drive to another drive, the drive’s “personality” is
moved to the new drive. Alternatively, the data stored in the EEPROM
may be transferred using ULTRA Master software to a peripheral
device, such as diskette or tape.
The only time you may need to remove the personality module is if
you do not have a PC available and your drive is down.
EEPROM Removal/Replacement
To remove the EEPROM from a drive:
1. Remove all power from the drive
2. Disconnect all connections to the front of the drive.
3. Remove the protective cover by removing the screws attaching
the right-side cover to the chassis.
4. Refer to Figure 11.1 for the location of the personality module.
5. Grasp the EEPROM with an IC chip puller to remove the person-
ality module.
To install the EEPROM on a drive:
1. Remove all power from the drive.
2. Remove all connections to the front of the drive.
3. Remove the protective cover by removing the screws attaching
the right-side cover to the chassis.
4. Refer to Figure 11.1 for the location of the personality module.
!
Intro
ATTENTION: The circuits in the drive are potential
sources of severe electrical shock. Follow the safety guide-
lines to avoid shock.
!
Intro
ATTENTION: Electronic components are subject to
damage by static electricity. Follow Electrostatic Discharge
(ESD) practices while handling components.
