Publication 1398-5.0 – October 1998
TouchPad Instructions C-7
For example: If the SpeedWin setting is 5000 rpm and the
Maximum Speed in the motor table is 5200 , pressing the key
increases the parameter to 5200 (the upper limit), but pressing the
key decrements the parameter to 4000 .
The most significant digit is reserved when a parameter allows a
negative (-) setting or the parameter provides a list of possible
selections. The
or key toggles the minus sign.
List
The most significant digit is reserved for an active/inactive selection
marker when a parameter provides a list of possible selections.
●
A filled arrow, , in the most significant digit indicates the active
setting from a list of possible settings. Inactive settings are
indicated by a unfilled arrow,
.
For example: If the drive is functioning as Preset Controller in the
Velocity mode, pressing the
key from DRVPARAM scrolls
through the CmdSrc list which includes Presets , AuxEnc ,
StepDir , StepU/D , and Analog .
●
The Mode/Enter, , key selects a parameter from the list.
●
List selections that are undefined are indicated by Unknown .
This display indicates the TouchPad data table is incompatible
with the drive.
Lists are associated with all parameters, except DISPLAY and
DRVINFO . Refer to page C-13 for items in each list. Table C.17,
“Drive Status List for TouchPad” on page C-16 is read-only; all other
lists contain possible parameter selections. After an option is selected,
the display reverts to the parameter from which the option was
selected.
For example: Selection of the EncAlign parameter under STATUS
provides the options
Normal and Align. Selection of either
option returns you to the EncAlign display.
