Programming and Parameters 3-39
267 Reslvr0 Status
Indicates the status of the resolver option card port 0.
• Bit 0 [-Cable Tune] indicates that the cable tuning test is active.
• Bit 1 [-Tune Result] indicates the tuning parameter type. When set, it indicates the tuning is using the parameter database. When cleared, it indicates the
tuning is using derived data.
• Bit 2 [-Mtr Turning] indicates that the motor is turning.
• Bit 4 [Energized] indicates the resolver is energized.
• Bit 8 [Open Wire] indicates a problem with the cable (open circuit).
• Bit 9 [Power Supply] indicates a problem with the option card's power supply.
• Bit 10 [Diag Fail] indicates the option card has failed its power-up diagnostics.
268 Reslvr0 TP Sel
Enter or write a value to select Fault data displayed in Par 269 [Reslvr0 TP Data].
Default:
Options: 0
0
1
2
3 “Zero”
“Zero”
4 “R0 EPR”
“R0 Edge Time” 5 “R0 Edge Mode”
“R0 dEdge” 6 “R0 dTheta”
“R0 dTime” 7 “R0 Delta2Err”
269 Reslvr0 TP Data
Displays the data selected by Par 268 [Reslvr0 TP Sel].
Default:
Min/Max: 0
-/+2147483648 32-bit
Integer
270 Reslvr0 SpdRatio
Specifies the speed ratio for the resolver option card port 0. The speed ratio comes from
the following formula. Speed ratio = electrical revolutions / mechanical revolutions = pole
count / 2.
Default:
Options: 1
1
2
3 2 poles (x1)
2 Poles (x1)
4 8 Poles (x4)
4 Poles (x2) 5 10 Poles(x5)
6 Poles (x3)
271 Reslvr0 Carrier
Specifies the resolver carrier frequency for the resolver option card port 0.
Units:
Default:
Min/Max: Hz
0
0/10000 32-bit
Integer
272 Reslvr0 In Volts
Specifies the resolver input voltage for the resolver option card port 0.
Units:
Default:
Min/Max: Volt
0.0000
0.0000/31.0810 Floating
Point
273 Rslvr0 XfrmRatio
Specifies the resolver transform ratio for the resolver option card port 0.
Default:
Min/Max: 0.0000
0.0000/4.0950 Floating
Point
274 Reslvr0 CableBal
Specifies the resolver cable balance for the resolver option card port 0.
Default:
Min/Max: 0.0000
0.0000/255.0000 Floating
Point
275 Reslvr0 Type Sel
Specifies the type of resolver used.
Default:
Options: 0
0
1
2
3
4
5
6
7 “Disabled”
“Disabled”
8 “Reserved”
“T2014/2087x1” 9 “1326Ax 460v”
“T2014/2087x2” 10 “Reserved”
“T2014/2087x5” 11 “Reserved”
“MPL 460v”
12 “Reserved”
“Reserved” 13 “Reserved”
“Siemens 1FT6” 14 “AmciR11XC107”
“PrkrHn ZX600”
276 FB Opt1 Posit
Displays the position feedback (accumulator) from port 1 of the feedback option card.
Default:
Min/Max: 0
-/+2147483648 32-bit
Integer
277 FB Opt1 Spd Fdbk
Displays the speed feedback from port 1 of the feedback option card.
Units:
Default:
Min/Max:
Comm Scale: RPM
0.0000
-/+14000.0000
Par 4 [Motor NP RPM] = 1.0 Floating
Point
279 Opt 1 Regis Ltch
Displays registration data from port 1 of the feedback option card. This data is the value
of the position reference counter, latched by the external strobes. The strobe signal used
to trigger the latch is configurable by Par 280 [Opt 1 Regis Cnfg].
Default:
Min/Max: 0
-/+2147483648 32-bit
Integer
No.
Name
Description
Values Li
nkab
le
Read
-Wr
it
e
Da
ta
T
ype
Options
Res
er
ve
d
Res
er
ve
d
Res
er
ve
d
Res
er
ve
d
Selec
t OK
Diag F
ail
P
ow
er Supp
ly
Ope
n Wire
Res
er
ve
d
Res
er
ve
d
Res
er
ve
d
E
ner
gi
ze
d
-Ca
ble
Co
mp
-Mt
r T
ur
nin
g
-T
une
Re
sult
-Ca
ble
T
une
Default 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 = False
1 = True
