3-84 Programming and Parameters
1042 SL Rx P1 Regis
Displays received port 1 registration data, if direct received data is configured to be port 1
registration data by the Rx Direct Data Selector (Pars 1011-1014). Configure this
selection by using the Peer Communication window in the DriveExecutive programming
software.
Default:
Min/Max: 0
-/+2147483648 32-bit
Integer
1047 SL Rx Opt0 Regis
Displays received registration data from feedback option 1 (high resolution encoder
daughter card), if direct received data is configured to be feedback option 1 registration
data by the Rx Direct Data Selector (Pars 1011-1014). Configure this selection by using
the Peer Communication window in the DriveExecutive programming software.
Default:
Min/Max: 0
-/+2147483648 32-bit
Integer
1049 SL Clr Events
Set these bits to clear the corresponding event latches indicated in Par 1040 [SL Rcv Events].
1054 SL Dir Int Rx0
Displays the integer value of the Direct Received Data for word 0. Data transmitted from
one node to another must be the same data type. This parameter is paired with Par 1055
[SL Dir Real Rx0].
Default:
Min/Max: 0
-/+2147483648 32-bit
Integer
1055 SL Dir Real Rx0
Displays the floating point (real) value of the Direct Received Data for word 0. Data
transmitted from one node to another must be the same data type. This parameter is
paired with Par 1054 [SL Dir Int Rx0].
Default:
Min/Max: 0.0000
-/+2200000000.0000 Real
1056 SL Dir Int Rx1
Displays the integer value of the Direct Received Data for word 1. Data transmitted from
one node to another must be the same data type. This parameter is paired with Par 1057
[SL Dir Real Rx1].
Default:
Min/Max: 0
-/+2147483648 32-bit
Integer
1057 SL Dir Real Rx1
Displays the floating point (real) value of the Direct Received Data for word 1. Data
transmitted from one node to another must be the same data type. This parameter is
paired with Par 1056 [SL Dir Int Rx1].
Default:
Min/Max: 0.0000
-/+2200000000.0000 Real
1058 SL Dir Int Rx2
Displays the integer value of the Direct Received Data for word 2. Data transmitted from
one node to another must be the same data type. This parameter is paired with Par 1059
[SL Dir Real Rx2].
Default:
Min/Max: 0
-/+2147483648 32-bit
Integer
1059 SL Dir Real Rx2
Displays the floating point (real) value of the Direct Received Data for word 2. Data
transmitted from one node to another must be the same data type. This parameter is
paired with Par 1058 [SL Dir Int Rx2].
Default:
Min/Max: 0.0000
-/+2200000000.0000 Real
1060 SL Dir Int Rx3
Displays the integer value of the Direct Received Data for word 3. Data transmitted from
one node to another must be the same data type. This parameter is paired with Par 1061
[SL Dir Real Rx3].
Default:
Min/Max: 0
-/+2147483648 32-bit
Integer
1061 SL Dir Real Rx3
Displays the floating point (real) value of the Direct Received Data for word 3. Data
transmitted from one node to another must be the same data type. This parameter is
paired with Par 1060 [SL Dir Int Rx3].
Default:
Min/Max: 0.0000
-/+2200000000.0000 Real
1073 SL Buf Int Rx00
Displays the integer value of the Buffered Received Data for word 0. Data transmitted
from one node to another must be the same data type. This parameter is paired with Par
1074 [SL Buf Real Rx00].
Default:
Min/Max: 0
-/+2147483648 32-bit
Integer
1074 SL Buf Real Rx00
Displays the floating point (real) value of the Buffered Received Data for word 0. Data
transmitted from one node to another must be the same data type. This parameter is
paired with Par 1073 [SL Buf Int Rx00].
Default:
Min/Max: 0.0000
-/+2200000000.0000 Real
1075 SL Buf Int Rx01
Displays the integer value of the Buffered Received Data for word 1. Data transmitted
from one node to another must be the same data type. This parameter is paired with Par
1076 [SL Buf Real Rx01].
Default:
Min/Max: 0
-/+2147483648 32-bit
Integer
1076 SL Buf Real Rx01
Displays the floating point (real) value of the Buffered Received Data for word 1. Data
transmitted from one node to another must be the same data type. This parameter is
paired with Par 1075 [SL Buf Int Rx01].
Default:
Min/Max: 0.0000
-/+2200000000.0000 Real
1077 SL Buf Int Rx02
Displays the integer value of the Buffered Received Data for word 2. Data transmitted
from one node to another must be the same data type. This parameter is paired with Par
1078 [SL Buf Real Rx02].
Default:
Min/Max: 0
-/+2147483648 32-bit
Integer
No.
Name
Description
Values Li
nkab
le
Read
-Wr
it
e
Da
ta
T
ype
Options
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Op
t0
Re
gis
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
E1
Re
gi
s
E0
Re
gi
s
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 = False
1 = True
