Page 118

3-64
Programming and Parameters
No.
Name
Description
Values
Li
nk
ab
le
R
ead-
Wri
te
D
ata
T
ype
623
Real In11
Displays input word 11 of the controller communication format in floating point format.
Paired with Par 622 [Integer In11], which displays the same data in integer format.
Default:
Min/Max:
0.0000
-/+2200000000.0000
Real
624
Integer In12
Displays input word 12 of the controller communication format in integer format. Paired
with Par 625 [Real In12], which displays the same data in floating point format.
Default:
Min/Max:
0
-/+2147483648
32-bit
Integer
625
Real In12
Displays input word 12 of the controller communication format in floating point format.
Paired with Par 624 [Integer In12], which displays the same data in integer format.
Default:
Min/Max:
0.0000
-/+2200000000.0000
Real
626
Integer In13
Displays input word 13 of the controller communication format in integer format. Paired
with Par 627 [Real In13], which displays the same data in floating point format.
Default:
Min/Max:
0
-/+2147483648
32-bit
Integer
627
Real In13
Displays input word 13 of the controller communication format in floating point format.
Paired with Par 626 [Integer In13], which displays the same data in integer format.
Default:
Min/Max:
0.0000
-/+2200000000.0000
Real
628
Integer In14
Displays input word 14 of the controller communication format in integer format. Paired
with Par 629 [Real In14], which displays the same data in floating point format.
Default:
Min/Max:
0
-/+2147483648
32-bit
Integer
629
Real In14
Displays input word 14 of the controller communication format in floating point format.
Paired with Par 628 [Integer In14], which displays the same data in integer format.
Default:
Min/Max:
0.0000
-/+2200000000.0000
Real
630
Integer In15
Displays input word 15 of the controller communication format in integer format. Paired
with Par 631 [Real In15], which displays the same data in floating point format.
Default:
Min/Max:
0
-/+2147483648
32-bit
Integer
631
Real In15
Displays input word 15 of the controller communication format in floating point format.
Paired with Par 630 [Integer In15], which displays the same data in integer format.
Default:
Min/Max:
0.0000
-/+2200000000.0000
Real
632
Integer Out00
Displays output word 00 of the controller communication format in integer format. Paired
with Par 633 [Real Out00], which displays the same data in floating point format.
Default:
Min/Max:
0
-/+2147483648
✓ ✓ 32-bit
Integer
633
Real Out00
Displays output word 00 of the controller communication format in floating point format.
Paired with Par 632 [Integer Out00], which displays the same data in integer format.
Default:
Min/Max:
0.0000
-/+2200000000.0000
✓ ✓ Real
634
Integer Out01
Displays output word 01 of the controller communication format in integer format. Paired
with Par 635 [Real Out01], which displays the same data in floating point format.
Default:
Min/Max:
0
-/+2147483648
✓ ✓ 32-bit
Integer
635
Real Out01
Displays output word 01 of the controller communication format in floating point format.
Paired with Par 634 [Integer Out01], which displays the same data in integer format.
Default:
Min/Max:
0.0000
-/+2200000000.0000
✓ ✓ Real
636
Integer Out02
Displays output word 02 of the controller communication format in integer format. Paired
with Par 637 [Real Out02], which displays the same data in floating point format.
Default:
Min/Max:
0
-/+2147483648
✓ ✓ 32-bit
Integer
637
Real Out02
Displays output word 02 of the controller communication format in floating point format.
Paired with Par 636 [Integer Out02], which displays the same data in integer format.
Default:
Min/Max:
0.0000
-/+2200000000.0000
✓ ✓ Real
638
Integer Out03
Displays output word 03 of the controller communication format in integer format. Paired
with Par 639 [Real Out03], which displays the same data in floating point format.
Default:
Min/Max:
0
-/+2147483648
✓ ✓ 32-bit
Integer
639
Real Out03
Displays output word 03 of the controller communication format in floating point format.
Paired with Par 638 [Integer Out03], which displays the same data in integer format.
Default:
Min/Max:
0.0000
-/+2200000000.0000
✓ ✓ Real
640
Integer Out04
Displays output word 04 of the controller communication format in integer format. Paired
with Par 641 [Real Out04], which displays the same data in floating point format.
Default:
Min/Max:
0
-/+2147483648
✓ ✓ 32-bit
Integer
641
Real Out04
Displays output word 04 of the controller communication format in floating point format.
Paired with Par 640 [Integer Out04], which displays the same data in integer format.
Default:
Min/Max:
0.0000
-/+2200000000.0000
✓ ✓ Real
642
Integer Out05
Displays output word 05 of the controller communication format in integer format. Paired
with Par 643 [Real Out05], which displays the same data in floating point format.
Default:
Min/Max:
0
-/+2147483648
✓ ✓ 32-bit
Integer
643
Real Out05
Displays output word 05 of the controller communication format in floating point format.
Paired with Par 642 [Integer Out05], which displays the same data in integer format.
Default:
Min/Max:
0.0000
-/+2200000000.0000
✓ ✓ Real
644
Integer Out06
Displays output word 06 of the controller communication format in integer format. Paired
with Par 645 [Real Out06], which displays the same data in floating point format.
Default:
Min/Max:
0
-/+2147483648
✓ ✓ 32-bit
Integer
