Programming and Parameters
517
PMag Tune Cnfg
Configures the Permanent Magnet Motor tuning mode.
520
PM Q Inductance
Indicates the percent-per unit inductance of the motor stator in the torque producing
(q-axis).
Units:
Default:
Min/Max:
Comm Scale:
%
20.00
0.00/399.99
100 = 8192
✓ 16-bit
Integer
521
PM D Inductance
Indicates the percent-per unit inductance of the motor stator in the flux producing
(d-axis).
Units:
Default:
Min/Max:
Comm Scale:
%
20.00
0.00/399.99
100 = 8192
✓ 16-bit
Integer
522
PM Stator Resist
Indicates the percent-per unit resistance of the motor stator.
Units:
Default:
Min/Max:
Comm Scale:
%
1.50
0.00/100.00
100 = 8192
✓ 16-bit
Integer
523
PM Mtr CEMF Coef
Indicates the coefficient for Counter Electro Motive Force (CEMF) voltage, normalized to
base motor speed.
Units:
Default:
Min/Max:
Comm Scale:
%
89.99
0.00/399.99
100 = 8192
✓ 16-bit
Integer
526
MC Build Number
Displays the build number of the drive's Motor Control (MC) software.
Default:
Min/Max:
0
0/65535
16-bit
Integer
527
MC Firmware Rev
Displays the major and minor revision levels of the drive's Motor Control (MC) software.
Default:
Min/Max:
Comm Scale:
0.00
0.00/655.35
x 10
16-bit
Integer
533
Slip Ratio
Used by the Field Oriented Control - 2 (FOC2) mode. Indicates the present operating slip
frequency at 100% Torque Producing Current (Iqs) scaled to hertz x 100.
Units:
Default:
Min/Max:
Comm Scale:
Hz
0.00
0.00/327.67
x 10
16-bit
Integer
534
Stator Frequency
Displays stator frequency as a percentage of Par 3 [Motor NP Hertz].
Units:
Default:
Min/Max:
Comm Scale:
%
0.0
-/+800.0
x 10
16-bit
Integer
535
Iqs Command
Displays the torque producing (q-axis) current command.
Units:
Default:
Min/Max:
Comm Scale:
%
0.0
-/+800.0
x 10
16-bit
Integer
537
Ids Command
Displays the flux producing (d-axis) current command.
Units:
Default:
Min/Max:
Comm Scale:
%
0.0
-/+800.0
x 10
16-bit
Integer
539
Iqs Feedback
Displays torque producing (q-axis) current feedback.
Units:
Default:
Min/Max:
P.U.
0.0000
-/+8.0000
Real
540
Ids Feedback
Displays flux producing (d-axis) current feedback.
Units:
Default:
Min/Max:
P.U.
0.0000
-/+8.0000
Real
541
Vqs Command
Displays the command for initiation of voltage on the torque producing axis (q-axis).
Units:
Default:
Min/Max:
Comm Scale:
%
0
-/+200
100 = 8192
16-bit
Integer
542
Vds Command
Displays the command for initiation of voltage on the flux producing axis (d-axis).
Units:
Default:
Min/Max:
Comm Scale:
%
0
-/+200
100 = 8192
16-bit
Integer
