Programming and Parameters
3-95
1317
User Data Real 03
General purpose parameter available for storage of real data by the operator. This value
will be retained through a power cycle.
Default:
Min/Max:
0.0000
-/+2200000000.0000
Real
1318
User Data Real 04
General purpose parameter available for storage of real data by the operator. This value
will be retained through a power cycle.
Default:
Min/Max:
0.0000
-/+2200000000.0000
Real
1319
User Data Real 05
General purpose parameter available for storage of real data by the operator. This value
will be retained through a power cycle.
Default:
Min/Max:
0.0000
-/+2200000000.0000
Real
1320
User Data Real 06
General purpose parameter available for storage of real data by the operator. This value
will be retained through a power cycle.
Default:
Min/Max:
0.0000
-/+2200000000.0000
Real
1370
Switch Control
Set bits to control the two software SPDT switches.
• Bit 1 [SW Int 1 On] controls the integer switch. Setting bit 1 moves the value from Par 1371 [SW Int 1 NO] into Par 1373 [SW Int 1 Output]. Resetting this bit moves
the value of Par 1372 [SW Int 1 NC] into Par 1373 [SW Int 1 Output].
• Bit 2 [SW Real 1 On] controls the real switch. Setting bit 2 moves the value from Par 1374 [SW Real 1 NO] into Par 1376 [SW Real 1 Output]. Resetting this bit
moves the value of Par 1375 [SW Real 1 NC] into Par 1376 [SW Real 1 Output].
1371
SW Int 1 NO
The integer switch moves the value of this parameter into Par 1373 [SW Int 1 Output]
when bit 0 [SW Int 1 On] of Par 1370 [Switch Control] is set.
Default:
Min/Max:
0
-/+2147483648
✓ ✓ 32-bit
Integer
1372
SW Int 1 NC
The integer switch moves the value of this parameter into Par 1373 [SW Int 1 Output]
when bit 0 [SW Int 1 On] of Par 1370 [Switch Control] is reset.
Default:
Min/Max:
0
-/+2147483648
✓ ✓ 32-bit
Integer
1373
SW Int 1 Output
Displays the output of the integer switch. It will reflect the value of either Par 1371 [SW Int
1 NO] or 1372 [SW Int 1 NC].
Default:
Min/Max:
0
-/+2147483648
✓ ✓ 32-bit
Integer
1374
SW Real 1 NO
The real switch moves the value of this parameter into Par 1376 [SW Real 1 Output] when
bit 0 [SW Int 1 On] of Par 1370 [Switch Control] is set.
Default:
Min/Max:
0.0000
-/+2200000000.0000
Real
1375
SW Real 1 NC
The real switch moves the value of this parameter into Par 1376 [SW Real 1 Output] when
bit 0 [SW Int 1 On] of Par 1370 [Switch Control] is reset.
Default:
Min/Max:
0.0000
-/+2200000000.0000
Real
1376
SW Real 1 Output
Displays the output of the real switch. It will reflect the value of either Parameter 1374 [SW
Real 1 NO] or 1375 [SW Real 1 NC].
Default:
Min/Max:
0.0000
-/+2200000000.0000
Real
No.
Name
Description
Value
Li
nkab
le
Read
-Wr
it
e
Da
ta
T
ype
Options
Re
ser
ved
Re
ser
ved
Re
ser
ved
Re
ser
ved
Re
ser
ved
Re
ser
ved
Re
ser
ved
Re
ser
ved
Re
ser
ved
Re
ser
ved
Re
ser
ved
Re
ser
ved
Re
ser
ved
SW Real 1 On
SW In
t 1 On
Re
ser
ved
Default
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
Bit
15 14 13 12 11 10 9
8
7
6
5
4
3
2
1
0
0 = False
1 = True
