p-6
Overview
Catalog Number Explanation, Cont’d
c5
ND Rating
690V, 50 Hz Input
♣
Code
Amps
Hp
052
52
45
060
60
55
082
82
75
098
98
90
119
119
110
142
142
132
♣
CE Certification testing has not been
performed on 600V class drives.
d
Enclosure
Code
Enclosure
A
IP20, NEMA Type 1
N
Open/IP00
a
a
Frames 9 & up Only.
e
HIM
Code
Operator Interface
0
Blank Cover
2
Digital LCD
3
Full Numeric LCD
5
Prog. Only LCD
C
Full Numeric LCD,
Door Mount
7
7
Frames 10 & up only.
f
Documentation
Code
Documents
E
Quick Start Guide
N
No Documentation
g
Brake
Code
w/Brake IGBT
‡
Y
Yes
N
N o
‡
Brake IGBT is standard on Frames 1-3 and
optional on Frames 4-9 ONLY.
h
Brake Resistor
Code
w/Resistor
Y
Yes
9
N
N o
9
Not available for Frame 3 drives or larger.
i
Emission
Code
CE Filter
CM Choke
A
Yes
Yes
B
a
Yes
No
N
§
No
No
Frames 1-6 Only.
a
Frames 9 & up Only.
§
For use on ungrounded distribution systems
(Frame 9 drives only).
j
Comm Slot
Code
Version
N
None
C
DPI ControlNet (Coax)
D
DPI DeviceNet
E
DPI EtherNet/IP
Q
DPI ControlNet (Fiber)
R
DPI RIO
S
DPI RS-483 DF1
1
DriveLogix ControlNet (Coax)
2
DriveLogix ControlNet Redundant
(Coax)
3
DriveLogix ControlNet (Fiber)
4
DriveLogix ControlNet Redundant
(Fiber)
5
DriveLogix DeviceNet (Open Conn.)
6
DriveLogix EtherNet/IP
k
Control Options
Code
Control
Option
Logic
Expansion
Synch
-Link
Cassette
N
Phase I
N/A
Stand
ard
None
l
Feedback
Code
Option
N
None
A
Resolver
B Stegman
Hi-Resolution
Encoder
C Multi-Device
Interface
m
Additional Config.
Code
Description
N
Phase I Control
A
Phase I DriveLogix5720
B
Phase I DriveLogix5720
w/Expanded Memory
