Rockwell Automation 20D PowerFlex 700S Drive Ph I Control, Frames 1...11 - Manual (Page 83)

Programming and Parameters 3-29
186 PI Prop Gain
Controls the proportional gain of the Process Control regulator. If the proportional gain is
1.0, the regulator output equals 1 pu for 1 pu error.
Default:
Min/Max: 8.0000
0.0000/200.0000 ✓ ✓ Real
187 PI Integ Time
Controls the integral gain of the Process Control regulator. If the integrator time is 1.0, the
regulator output equals 1 pu in 1 second for 1 pu error.
Units:
Default:
Min/Max: /Sec
8.0000
0.0000/4000.0000 ✓ ✓ Real
188 PI Integ HLim
The high limit of the integral gain channel for the Process Control regulator. A value of 1
can represent either base motor speed, motor rated torque, or 100% for some external
function.
Units:
Default:
Min/Max: P.U.
0.1000
0.0000/8.0000 ✓ ✓ Real
189 PI Integ LLim
The low limit of the integral gain channel for the Process Control regulator. A value of 1
can represent either base motor speed, motor rated torque, or 100% for some external
function.
Units:
Default:
Min/Max: P.U.
-0.1000
-8.0000/0.0000 ✓ ✓ Real
190 PI Integ Output
Displays the output value of the integral channel of the Process Control regulator. A value
of 1 can represent either base motor speed, motor rated torque, or 100% for some
external function.
Units:
Default:
Min/Max: P.U.
0.0000
-/+8.0000 Real
191 PI High Limit
The high limit of the Process Control regulator output. A value of 1 can represent either
base motor speed, motor rated torque, or 100% for some external function.
Units:
Default:
Min/Max: P.U.
0.1000
0.0000/8.0000 ✓ ✓ Real
192 PI Lower Limit
The low limit of the Process Control regulator output. A value of 1 can represent either
base motor speed, motor rated torque, or 100% for some external function.
Units:
Default:
Min/Max: P.U.
-0.1000
-8.0000/0.0000 ✓ ✓ Real
193 PI TP Sel
Enter or write a value to select Process Control PI data displayed by Par 194 [PI TP
Data].
Default:
Options: 0
0
1
2
3
4
5 “Zero”
“Zero”
6 “On Out Limit”
“PI Error” 7 “Extern Hold”
“LPF Output” 8 “Hold Status”
“P Gain Term” 9 “Enbl Status”
“Reg Output” 10 “Time Axis En”
“On Intg Lim”
194 PI TP Data
Displays the data selected by Par 193 [PI TP Sel].
Units:
Default:
Min/Max: P.U.
0.0000
-/+8.0000 Real
200 Time Axis Rate
Sets rate (1/sec) for the Time Function Generator to ramp from and output of 0 to 1 and
from 1 to 0.
Units:
Default:
Min/Max: /Sec
1.0000
0.0100/20.0000 ✓ ✓ Real
201 Time Axis Output
The output of the Time Function Generator. When the Time Function Generator is
enabled by Par 183 [PI Command] bit 1 [Enable] or Par 151 [Logic Command] bit 3 [Time
Axis En], the value of this parameter ramps from 0 to 1 at a rate determined by Par 200
[Time Axis Rate]. Conversely, when the Function Generator is disabled, the value of this
parameter ramps from 1 to 0.
Default:
Min/Max: 0.0000
0.0000/1.0000 Real
204 LimGen Y axis Mx
Sets Par 207 [Limit Gen Hi Out] and Par 208 [Limit Gen Lo Out] when the absolute value
of Par 206 [LimGen X axis In] is greater than or equal to 1.
Units:
Default:
Min/Max: P.U.
0.2500
0.0000/8.0000 ✓ ✓ Real
205 LimGen Y axis Mn
Sets Par 207 [Limit Gen Hi Out] and Par 208 [Limit Gen Lo Out] when the absolute value
of Par 206 [LimGen X axis In] is equal to 0.
Units:
Default:
Min/Max: P.U.
0.0500
0.0000/8.0000 ✓ ✓ Real
206 LimGen X axis In
The X axis input to the Limit Generator. Typically this parameter is linked to a speed
reference or to Par 201 [Time Axis Output].
Default:
Min/Max: 0.0000
-/+8.0000 ✓ ✓ Real
207 Limit Gen Hi Out
Displays the positive output of the Limit Generator. When Par 206 [Limit Gen X axis In] is
greater than or equal to 1, this value equals Par 204 [LimGen Y axis Mx]. When Par 206
[LimGen X axis In] is equal to 0, this value equals Par 205 [LimGen Y axis Mn]. For
values of X Axis input between 0 and 1, the value of this parameter is interpolated from Y
axis min and max values. Typically this parameter is linked to Par 191 [PI High Limit].
Units:
Default:
Min/Max: P.U.
8.0000
0.0000/8.0000 Real
208 Limit Gen Lo Out
Displays the negative output of the Limit Generator. The value of this parameter is the
negative of Par 207 [Limit Gen Hi Out]. Typically it is linked to Par 192 [PI Lower Limit].
Units:
Default:
Min/Max: P.U.
-8.0000
-8.0000/0.0000 Real
No.
Name
Description
Values Li
nkab
le
Read
-Wr
it
e
Da
ta
T
ype
