3-94 Programming and Parameters
1265 Trend In1 Real
Provides real input to the Trend 1 function. The Trending function samples this parameter
for Trend Buffer 1, if bit 1 [In 1 Real] of Par 1250 [Trend Control] is set.
Default:
Min/Max: 0.0000
-/+2200000000.0000 ✓ ✓ Real
1266 Trend In2 Int
Provides integer input to the Trend 2 function. The Trending function samples this
parameter for Trend Buffer 2, if bit 2 [In 2 Real] of Par 1250 [Trend Control] is cleared.
Default:
Min/Max: 0
-/+2147483648 ✓ ✓ 32-bit
Integer
1267 Trend In2 Real
Provides real input to the Trend 2 function. The Trending function samples this parameter
for Trend Buffer 2, if bit 2 [In 2 Real] of Par 1250 [Trend Control] is set.
Default:
Min/Max: 0.0000
-/+2200000000.0000 ✓ ✓ Real
1268 Trend In3 Int
Provides integer input to the Trend 3 function. The Trending function samples this
parameter for Trend Buffer 3, if bit 3 [In 3 Real] of Par 1250 [Trend Control] is cleared.
Default:
Min/Max: 0
-/+2147483648 ✓ ✓ 32-bit
Integer
1269 Trend In3 Real
Provides real input to the Trend 3 function. The Trending function samples this parameter
for Trend Buffer 3, if bit 3 [In 3 Real] of Par 1250 [Trend Control] is set.
Default:
Min/Max: 0.0000
-/+2200000000.0000 ✓ ✓ Real
1270 Trend In4 Int
Provides integer input to the Trend 4 function. The Trending function samples this
parameter for Trend Buffer 4, if bit 4 [In 4 Real] of Par 1250 [Trend Control] is cleared.
Default:
Min/Max: 0
-/+2147483648 ✓ ✓ 32-bit
Integer
1271 Trend In4 Real
Provides real input to the Trend 4 function. The Trending function samples this parameter
for Trend Buffer 4, if bit 4 [In 4 Real] of Par 1250 [Trend Control] is set.
Default:
Min/Max: 0.0000
-/+2200000000.0000 ✓ ✓ Real
1280 Trend Marker Int
Marks the start of data for trend buffers that are using integer data. The Trend Marker can
be used to provide a scope trigger signal for the Auto Output function.
Default:
Min/Max: 0
-/+2147483648 ✓ ✓ 32-bit
Integer
1281 Trend Marker Real
Marks the start of data for trend buffers that are using real data. The Trend Marker can be
used to provide a scope trigger signal for the Auto Output function.
Default:
Min/Max: 0.0000
-/+2200000000.0000 ✓ ✓ Real
1283 TrendBuffPointer
Selects the trend buffer element to be displayed in the Trend Output Parameters when the
trend function is inactive (not collecting data samples). A zero value points to the element
that corresponds to the trigger event. Negative values point to pre-trigger data. Positive
values point to post-trigger data. When the Auto Output function is running, this
parameter will automatically sequence through it's full range, at a rate set by Par 1253
[Trend Rate].
Default:
Min/Max: 0
-/+1023 ✓ ✓ 16-bit
Integer
1284 Trend Out1 Int
Displays the output for Trend Buffer 1, if the buffer is using integer data. This will equal the
value of the element, in Trend Buffer 1, specified by Par 1283 [TrendBuffPointer].
Default:
Min/Max: 0
-/+2147483648 32-bit
Integer
1285 Trend Out1 Real
Displays the output for Trend Buffer 1, if the buffer is using real data. This will equal the
value of the element, in Trend Buffer 1, specified by Par 1283 [TrendBuffPointer].
Default:
Min/Max: 0.0000
-/+2200000000.0000 Real
1286 Trend Out2 Int
Displays the output for Trend Buffer 2, if the buffer is using integer data. This will equal the
value of the element, in Trend Buffer 2, specified by Par 1283 [TrendBuffPointer].
Default:
Min/Max: 0
-/+2147483648 32-bit
Integer
1287 Trend Out2 Real
Displays the output for Trend Buffer 2, if the buffer is using real data. This will equal the
value of the element, in Trend Buffer 2, specified by Par 1283 [TrendBuffPointer].
Default:
Min/Max: 0.0000
-/+2200000000.0000 Real
1288 Trend Out3 Int
Displays the output for Trend Buffer 3, if the buffer is using integer data. This will equal the
value of the element, in Trend Buffer 3, specified by Par 1283 [TrendBuffPointer].
Default:
Min/Max: 0
-/+2147483648 32-bit
Integer
1289 Trend Out3 Real
Displays the output for Trend Buffer 3, if the buffer is using real data. This will equal the
value of the element, in Trend Buffer 3, specified by Par 1283 [TrendBuffPointer].
Default:
Min/Max: 0.0000
-/+2200000000.0000 Real
1290 Trend Out4 Int
Displays the output for Trend Buffer 4, if the buffer is using integer data. This will equal the
value of the element, in Trend Buffer 4, specified by Par 1283 [TrendBuffPointer].
Default:
Min/Max: 0
-/+2147483648 32-bit
Integer
1291 Trend Out4 Real
Displays the output for Trend Buffer 4, if the buffer is using real data. This will equal the
value of the element, in Trend Buffer 4, specified by Par 1283 [TrendBuffPointer].
Default:
Min/Max: 0
-/+2200000000.0000 Real
1300 User Data Int 05
General purpose parameter available for storage of 32-bit enumerated data by the
operator. This value will be retained through a power cycle.
Default:
Min/Max: 0
-/+2147483648 ✓ ✓ 32-bit
Integer
1301 User Data Int 06
General purpose parameter available for storage of 32-bit enumerated data by the
operator. This value will be retained through a power cycle.
Default:
Min/Max: 0
-/+2147483648 ✓ ✓ 32-bit
Integer
1315 User Data Real 01
General purpose parameter available for storage of real data by the operator. This value
will be retained through a power cycle.
Default:
Min/Max: 0.0000
-/+2200000000.0000 Real
1316 User Data Real 02
General purpose parameter available for storage of real data by the operator. This value
will be retained through a power cycle.
Default:
Min/Max: 0.0000
-/+2200000000.0000 Real
