Appendix
F
PowerFlex 700S Resolver Feedback Option
Card
Chapter Objectives
Specifications Resolver Feedback Option Card Specifications
Compatible Resolvers
Table G specifies which resolvers are supported by the 700S Resolver
Feedback Option module.
Table G Compatible Resolvers .
Allen-Bradley servo motors may be ordered with factory installed resolvers.
Table H specifies which factory installed resolvers are supported by the
700S Resolver Feedback Option module.
For Information on … See Page...
Chapter Objectives F-1
Specifications F-1
Consideration Description
Excitation Frequency 2400 Hz
Excitation Voltage 26 Vrms
Resolver Feedback Voltage 2 Vrms +/- 300 mV
Customer-I/O plug (P1) Allen-Bradley PN: S94262908
Weidmuller PN: BL3.50/90/8BK
Manufacturer
Manufacturer Catalog
Number
Notes
Tamagawa TS-2014N181E32 x 1, flange-mounted enclosure
Tamagawa TS-2014N182E32 x 2, flange-mounted enclosure
Tamagawa TS-2014N185E32 x 5, flange-mounted enclosure
Tamagawa TS-2087N12E9 x 2, HD foot-mounted enclosure,
double shaft
Tamagawa TS-2087N1E9 x 1, HD foot-mounted enclosure
Tamagawa TS-2087N2E9 x 2, HD foot-mounted enclosure
Tamagawa TS-2087N5E9 x 5, HD foot-mounted enclosure
Tamagawa TS-2087N11E9 x 1, HD foot-mounted enclosure,
double shaft
Advanced Micro Controls Inc. (AMCI) R11X-C10/7
