3120290 2-15
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
FIGURE 2-3. RACINE PROPORTIONAL CONTROL VALVE ASSEMBLY - OUTLET SECTION.
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
4640455
RACINE PROPORTIONAL CONTROL VALVE
ASSEMBLY - OUTLET SECTION (3 SECTION)
Ref. -
4640456
RACINE PROPORTIONAL CONTROL VALVE
ASSEMBLY - OUTLET SECTION (4 SECTION)
Ref. -
1 7004885 Outlet Section (3 Section Valve) (Includes Items 4-12) 1
7002368 Outlet Section (4 Section Valve) (Includes Items 4-12) 1
2 7004869 Nut 4
3 7004870 Stud 4
4 7004871 Plug 1
5 Kit O-Ring 1
— — — — — — — — — —
7004872 Cartridge Assembly, Pilot Pressure 1
7002288 Plug and O-Ring Assembly 1
6 7004873 Plug 1
7 Kit O-Ring 1
8 7004874 Spring 1
9 7002287 Poppet 1
10 7004875 Housing 1
11 Kit O-Ring 1
12 Kit O-Ring 1
13 7004891
Swing and Telescope Valve Sections (See Figure 2-4
for Breakdown)
1
14 7004888 Lift Valve Section (See Figure 2-4 for Breakdown) 1
15 7004890 Drive Valve Section (See Figure 2-4 for Breakdown) 1
16 7002364 Inlet Manifold (See Figure 2-5 for Breakdown) 1
17 7004884 Servo Assembly (See Figure 2-6 for Breakdown) 1
— — — — — — — — — —
7004833
Seal Kit - 7004885 Outlet Section (Includes Items 5, 7,
11 and 12) (4 Section Valve)
1
