SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
32
0700617
Bolt, Metric 6mm x 45mm
A/R
33
Not Used
34
Not Used
35
0901402
Bracket, Terminal Strip
1
36
1320060
Clamp
1
37
1670414
Cover, Terminal Strip
1
38
3910812
Screw, Machine #8-32NC x 3/4”
2
39
4770800
Starwasher #8
2
40
3310801
Nut #8-32NC
2
41
1700821
Decal - Wire Identification
1
42
Air Intake Weldment Options:
1
4843320
Engine, Deutz F3L912
4843384
Engine, Deutz F4L912
43
4565269
Adapter, Exhaust
1
44
1320011
Clamp, Exhaust
1
45
Not Used
46
2750527
Hose
1
47
Not Used
48
4751400
Flatwasher 1/4”
A/R
49
0641416
Bolt 1/4”-20NC x 2”
2
50
Not Used
51
3311505
Locknut 5/16”-18NC
2
52
4751500
Flatwasher 5/16”
4
53
0700810
Bolt Metric 8mm x 20mm
2
54
4751500
Flatwasher
2
55
4761500
Lockwasher
2
56
0701217
Bolt Metric 12mm x 45mm
4
57
1320222
Clamp (S/N 38256 to Present)
1
0253386
DEUTZ ENGINE INSTALLATION - STANDARD
F3L912
Ref.
E
0253388
DEUTZ ENGINE INSTALLATION - CLEAN BURN
F3L912
Ref.
E
0253328
DEUTZ ENGINE INSTALLATION - F4L912
Ref.
E
77
0641408
Bolt 1/4”-20NC x 1”
4
78
Tube Options:
1
Not Required
Engine, Deutz F3L912
4844238
Engine, Deutz F4L912
79
4420001
Tape, Sealant
A/R
80
1340020
Air Cleaner Assembly (See Section 10 for Hostile
Environment/Non-Standard Air Cleaners)
1
7004214
Filter
1
81
0340020
Band, Mounting
2
82
0080046
Elbow
1
83
0080039
Elbow
A/R
84
Tube Options:
1
4565877
Engine, Deutz F3L912
4565655
Engine, Deutz F4L912
FIGURE 2-25. DEUTZ ENGINE INSTALLATION WITH NOISE REDUCTION (BUILT DECEMBER 1992
TO PRESENT) (CONTINUED)
