3-6 3120290
SECTION 3 BOOM
S
E
C
T
I
O
N
3
B
O
O
M
58 Pin Options: 1
3420420 Pin (Prior to June 1985)
3421228 Pin (June 1985 to Present)
59 0641610 Bolt 3/8”-16NC x 1 1/4” 12
60 4070496 Shim 1/16” A/R
61 4070509 Shim 1/8” A/R
62 0651808 Bolt 1/2”-20NF x 1” 1
63 4740003 Washer, Hardened 1
64 2160002 Fitting, Grease 4
65 3421029 Pin, Clevis 2
66 4711400 Flatwasher 1/4” Narrow 6
67 3450203 Pin, Cotter 1/16” x 3/4” 6
68 0960979 Bushing, Eccentric 2
69 3340397 Pad, Wear 2
70 0641609 Bolt 3/8”-16NC x 1 1/8” 6
71 4751600 Flatwasher 3/8” 10
72 4300042 Stud 6
73 3311602 Nut, Jam 3/8”-16NC 10
74 3311401 Nut 1/4”-20NC 19
75 Pad, Wear Options: 1
3340405 Machines with Standard Control
Not Required Machines with Hydraulic Control
76 0641414 Bolt 1/4”-20NC x 1 3/4” 2
77 1320121 Clamp, Powertrack 1
78 4751400 Flatwasher 1/4” 14
79 4761400 Lockwasher 1/4” 19
80 3520029 Plug, Hole (Prior to S/N 46278) 2
81 Carrier, Hose and Cable Options: A/R
60H/60H+6 with Standard Control 1
Use 1001119692 Gemco Replacement Parts (was p/n 1180104): 1
7006130 1 Foot Section 1
7006133 Feet, Mounting 4
7006131 1 Foot Section with Mounting Feet 2
7006138 Pin Kit A/R
7006159 Tool Kit 1
1001119692 Gortrac Replacement Parts: 1
70003147 Section Repair Kit (6 Links) 1
70003148 Bracket, Mounting Kit 1
1180181 60H with Hydraulic Control 1
7006165 1 Foot Section 1
7006143 Feet, Mounting 4
7006155 Rod, Spring Loaded A/R
1180136 70H with Standard Control 1
7006130 1 Foot Section 1
7006133 Feet, Mounting 4
7006131 1 Foot Section with Mounting Feet 2
7006138 Pin Kit A/R
7006159 Tool Kit 1
FIGURE 3-1. BOOM COMPONENT ASSEMBLIES (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
