3120290 4-3
SECTION 4 PLATFORMS
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
S
FIGURE 4-1. STANDARD PLATFORM AND FOOTSWITCH INSTALLATION
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
STANDARD PLATFORM AND FOOTSWITCH
INSTALLATION Ref.
0236830 FIXED SUPPORT INSTALLATION - MODEL 60H/70H Ref. A
0238154 FIXED SUPPORT INSTALLATION - MODEL 60H+6 Ref. B
1 Support Weldment Options: 1
4842403 Support Weldment (60H/70H)
0961024 Bushing 2
4842817 Support Weldment (60H+6) (Not Shown)
0961185 Bushing 2
2 Pin Options: 1
3421176 60H/70H
60H+6 Options:
3421426 Pin (Prior to January 1991)
3421825 Pin (January 1991 to November 1991)
3422019 Pin (November 1991 to Present)
3 Bolt Options: 1
0641608 Bolt 3/8”-16NC x 1” (60H/70H)
0641405 Bolt 1/4”-20NC x 5/8” (Use After November 1991
Only) (60H+6)
4 2160002 Fitting, Grease A/R
5 0681610 Bolt 3/8”-16NC x 1 1/4” 10
6 4751600 Flatwasher 3/8” A/R
7 Locknut Options: 10
3311605 Locknut 3/8”-16NC (60H/70H)
3300143 Locknut 3/8” (60H+6)
8 4761600 Lockwasher 3/8” 1
9 Nut 3/8”-16NC Options: 1
3311601 60H/70H
Not Required 60H+6
10 Hardware Options: 1
60H/70H Options:
Plate (Part of Item 2)
60H+6 Options:
Retainer Options:
Not Required (Prior to January 1991)
4740385 Washer (January 1991 to November 1991)
0362079 Bar (November 1991 to Present)
3900159 Screw, Countersunk 1/2”-13NC x 3/4” (Not
Shown - Used After January 1991)
3760237 Ring, Retaining (Not Shown - Used Prior to Jan-
uary 1991)
