JLG 70H Parts Manual User Manual
Page 210
2-132
3120290
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
18
4761000
Lockwasher #10
2
19
3311001
Nut #10-24NC
2
20
Not Used
21
3251476
Decal - On/Off
1
22
Cable, Electrical -12/4 Options:
3ft/.9m
1060012
Prior to S/N 60653
1060515
S/N 60653 to February 1995
23
4460134
Connector (Not Shown - Located at Generator)
1
24
4460071
Connector (Not Shown - Located at Ground Control
box)
1
25
3300048
Locknut, Conduit (Not Shown - Located at Ground
Control Box)
1
26
0960238
Bushing (Not Shown - Located at Ground Control
Box)
1
27
4460023
Connector, Terminal (Not Shown - Located at
Generator Control Box)
1
28
2860012
Key
1
29 to 30
Not Used
31
4761600
Lockwasher 3/8”
A/R
0236382
GENERATOR INSTALLATION (PRIOR TO MAY 1987)
(VARIABLE PARTS)
Ref.
C
0236383
GENERATOR INSTALLATION (MAY 1987 THROUGH
1988)
Ref.
F
51
4060579
Shield, Heat
1
52
3311501
Nut 5/16”-18NC
4
53
4340436
Support, Adjustable
1
54
Support Options:
1
4340437
(Prior to May 1987)
4340438
(May 1987 through 1988)
55
0630135
Bolt, Metric 10mm x 30mm
2
0239244
GENERATOR INSTALLATION (1989 TO MAY 1991)
(VARIABLE PARTS)
Ref.
I
0251947
GENERATOR INSTALLATION (MAY 1991 TO
FEBRUARY 1995) (VARIABLE PARTS)
Ref.
4
71
4060696
Shield, Heat
1
72
Not Used
73
4340565
Support, Adjustable
1
74
4843156
Support Weldment
1
75
4564123
Tube, Spacer
A/R
76
4564329
Tube, Spacer
1
77
4740116
Lockwasher, Metric 10mm
4
78
0361704
Bar, Mounting
1
79
0701022
Bolt, Metric 10mm x 70mm
4
80
4564328
Tube, Spacer
1
81
0681610
Bolt 3/8”-16NC x 1 1/4” (Grade 8)
3
82
4751600
Flatwasher 3/8”
3
FIGURE 2-31. GENERATOR INSTALLATION - FORD ENGINE MACHINES BUILT PRIOR TO
FEBRUARY 1995 (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
